GW Instek GDS-3000 Series Digital Storage Oscilloscope

The GDS-3000 Series is a new platform of 4-input channels, 500MHz bandwidth, 5GSa/s sampling rate, and VPO waveform display. The split screen feature has been designed to meet the requirements of multi-window and multi-signal tests in the research and manufacturing fields. The optional power analysis software and the optional serial bus analysis software are available to facilitate the engineer’s tasks in testing and manufacturing of associated products.

Categories ,


Three new differential probes, GDP-025, GDP-050, and GDP-100, also two new current probes, GCP-005, GCP-020, GCP-100 and GCP-530 and GCP-1030, are coming along with the GDS-3000 Series to provide total solutions for a wide variety of applications in industry, service and education market sectors. The GDS-3000 Series, a high-tech platform carrying thoughtful features, brings very high customer value to both general purpose market and the professional market.

GW Instek GDS-3000 Series Features:

  • 500MHz, 350MHz, 150MHz Bandwidths and 2 or 4 Channels.
  • 5GSa/s Real Time or 100GS/s Equivalent Time Sampling Rate.
  • Independent Memory for each Channel.
  • Visual Persistence Oscilloscope (VPO) Technology.
  • Large 8-inch TFT LCD color Display, LED Back-light, and 800 x 600 pixels (SVGA).
  • Split Screen Function.
  • 3 Built-in Input Impedances (500Ω, 75Ω, and 1MΩ).
  • Optional Power Analysis Software for Power Source Measurement and Analysis.
  • Optional Serial Bus Analysis Software for Trigger and Decode of I2C, SPI and UART Interfaces
